OVERVIEW
The S-Tipper from Crysteel is designed for contractors looking for added corrosion protection from harsh environments and corrosive materials. High strength and impact resistance mean a long, functional working life for this dump body. In fact, because of the S-Tipper’s extended life cycle, can be the best value over other material options.
The S-Tipper offers a clean, modern appearance and brings a tough, long-lasting profile to any fleet.
Materials
- Constructed of 201 stainless steel
- 12 gauge sides
- 10 gauge floor (rigid sides)
- 7 gauge floor (fold-down sides)
Specifications
- Lengths: 8’1″, 9′, 9’6″, 10′, 10’6″, 11′, 11’6″, 12′
- Side Heights: 10″ – 22″
- Capacities: 2.2 – 5.4 cu yds.
- Inner / Outer Width: 87″/96″
Features & Options
- Crossmemberless understructure
- Smooth, single-wall sides – 6″ Side board pockets
- Integral cabshield with plasma cut window
- Full height corner posts with radius corner pillars
- Single-lever Quick-Drop tailgate
- Spreader chains and chain slot brackets on corner posts
- Integrated tarp receivers
- Double panel tailgate
